Pondmaster Pond‑Mag Magnetic Drive Water Pumps
Pondmaster Pond‑Mag Magnetic Drive Water Pumps
In stock
Starting Price:
Regular price $166.59 CAD
Regular price
Sale price
$166.59 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
QUICK OVERVIEW
Pondmaster Pond-Mag® Magnetic Drive Water Pumps are designed to handle a wide range of water-moving applications in pond environments. They offer quiet, efficient 24/7 operation with a magnetic impeller assembly and an epoxy-encased power unit to help prevent contamination.
Warranty
Coverage
- 5-year limited warranty
- Applies to the pump family covered by the manufacturer product line
- Covers defects in materials and workmanship under normal use
Service Requirements
- Proof of purchase is typically required for warranty support
- Use according to the manufacturer instructions and rated application
- Maintain the pump in accordance with routine care guidance
Important Conditions
- Improper installation, misuse, or non-approved modifications may affect coverage
- Consumable or wear items may be treated separately from the main unit
- Refer to the latest manufacturer warranty information for full details
Warranty information is based on current Danner Manufacturing product-family pages for magnetic drive pumps.
Components Included
Pump or Compressor Assembly
- Primary motor and operating assembly based on the selected product family
- Designed for continuous-duty or routine water-feature use depending on model
- Supports reliable flow or air delivery performance
Connection System
- Power cord, air outlet, inlet, fittings, or plumbing connection points depending on model
- Designed for integration into pond, waterfall, or aeration systems
- Supports practical installation and service access
Application Hardware
- Protective housings, cages, cabinets, or family-specific accessories may apply depending on product type
- Supports stable operation and long-term system performance
- Configured according to the selected model family
Included components vary by selected model, flow range, or compressor size. Mounting, control, and plumbing accessories may be configured separately.
Technical Specifications
| Model | Item # | Max. Watts/Amps | Volts | Inlet | Outlet | Cord Length | Dimensions (L × W × H) |
|---|---|---|---|---|---|---|---|
| PM 250 | 02522 | 24 / 0.4 | 120 / 60Hz | 1/2" FPT | 1/2" MPT | 18' | 5.0" × 3.8" × 4.2" |
| PM 350 | 02523 | 35 / 0.6 | 120 / 60Hz | 1/2" FPT | 1/2" MPT | 18' | 5.0" × 3.8" × 4.2" |
| PM 500 | 02525 | 45 / 0.9 | 120 / 60Hz | 1/2" FPT | 1/2" MPT | 18' | 5.0" × 3.8" × 4.2" |
| PM 700 | 02527 | 70 / 1.6 | 120 / 60Hz | 1/2" FPT | 1/2" MPT | 18' | 5.0" × 3.8" × 4.2" |
| PM 950 | 02720 | 93 / 1.33 | 120 / 60Hz | 3/4" FPT | 3/4" MPT | 18' | 5" × 3" × 5.25" |
| PM 1200 | 02722 | 110 / 1.5 | 120 / 60Hz | 3/4" FPT | 3/4" MPT | 18' | 6.4" × 3" × 5.25" |
| PM 1800 | 02728 | 145 / 1.55 | 120 / 60Hz | 3/4" FPT | 3/4" MPT | 18' | 6.4" × 3" × 5.25" |
| PM 2400 | 02750 | 237 / 2.2 | 120 / 60Hz | 1" FPT | 1" MPT | 18' | 7.25" × 4.0" × 6" |
| PM 3600 | 02755 | 256 / 3.0 | 120 / 60Hz | 1" FPT | 1" MPT | 18' | 7.25" × 4.0" × 6" |
Select the Pond-Mag model by required flow rate, inlet/outlet size, and available head height for your pond, waterfall, or fountain application.
Pondmaster pond mag magnetic drive water pumps.pdf
Model Options
Available configurations and product variants differ by the specific family shown below.
Pump Family Options
- Available in multiple flow capacities depending on the product family
- Choose the model based on feature size, required flow, and debris-handling needs
- Suitable for pond, waterfall, and filtration applications
Installation Configurations
- Designed for submerged or direct-use operation depending on model
- Supports common pond and water feature plumbing layouts
- Select the configuration that matches system head and installation space
Application Fit
- Smaller models suit compact features and moderate circulation
- Larger models support high-flow waterfalls and broader turnover needs
- Choose based on performance target and system design
Key Features
Efficient Water Movement
- Designed to deliver reliable flow for ponds, waterfalls, and water features
- Supports consistent circulation and water turnover
- Suitable for continuous-duty water movement applications
Durable Operating Design
- Built for wet-environment performance
- Engineered for long-term use in water feature systems
- Designed to balance performance, reliability, and service life
Application Flexibility
- Suitable for ponds, waterfalls, filtration systems, or general water transfer depending on model
- Available across multiple flow ranges and installation needs
- Designed to support both residential and commercial-style water features
