Warranty
2-Year Coverage
- Applies to all 3400R and 3400HR replacement motors (3/4HP)
- Covers defects in materials and workmanship under normal use
- Same coverage class as new 3/4HP Kasco units
Conditions
- Install per the owner's manual with GFCI-protected power
- Maintain the sacrificial zinc anode — a depleted anode leads to corrosion damage not covered by warranty
- Keep intake screens clear to avoid overheating
Warranty Support
- Fountain Depot is an authorized Kasco repair shop
- We handle warranty evaluation and claims locally in the GTA
- Call 905-752-1226 with your model and serial number
Warranty coverage is based on current Kasco replacement motor warranty information. For full terms, exclusions, and repair procedures, refer to the latest official Kasco documentation.
Components Included
Motor Assembly
- Sealed 3/4HP motor unit (120V or 240V per selection)
- Oil-cooled continuous-duty design
- Zinc anode installed on the shaft
Power Cord
- 3 ft stub with quick-disconnect, or
- Full-length 25, 50, or 100 ft cord
- Per the configuration you select
Not Included
- Float, prop/impeller & cage — transfer from your unit
- Control panel — reuse existing
- Nozzles and mooring hardware
The replacement motor swaps into your existing float, cage, and prop assembly. If you'd rather not do the swap yourself, our shop can install it — we service Kasco units in-house.
Technical Specifications
| Part Number | HP | Voltage | Phase | Cord | Fits Series | Warranty |
|---|---|---|---|---|---|---|
| 3400R000 | 3/4 | 120V | 1 | 3 ft stub (quick-disconnect) | Kasco 3400 | 2 Years |
| 3400R025 | 3/4 | 120V | 1 | 25 ft | Kasco 3400 | 2 Years |
| 3400R050 | 3/4 | 120V | 1 | 50 ft | Kasco 3400 | 2 Years |
| 3400R100 | 3/4 | 120V | 1 | 100 ft | Kasco 3400 | 2 Years |
| 3400HR000 | 3/4 | 208-240V | 1 | 3 ft stub (quick-disconnect) | Kasco 3400H | 2 Years |
| 3400HR050 | 3/4 | 208-240V | 1 | 50 ft | Kasco 3400H | 2 Years |
| 3400HR100 | 3/4 | 208-240V | 1 | 100 ft | Kasco 3400H | 2 Years |
Fits Kasco 3400 series equipment — 3400JF/VFX fountains, 3400AF surface aerators, 3400C AquatiClear circulators, and 3400D de-icers. "H" models (3400HJF, 3400HD) require the 240V motor.
Choose the 3 ft stub option only if your existing power cord has the matching quick-disconnect fitting and is in good condition. Unsure? Call 905-752-1226 with your model and serial number and we'll confirm the right configuration.
Kasco j series fountain manual .pdf
Model Options
Kasco replacement motors are matched to your unit's series — the first four digits of your model number (e.g. 3400JF takes a 3400 motor). We stock the full range.
2400R — 1/2HP, 120V
- Fits all Kasco 2400 series units
3400R / 4400R — 3/4HP & 1HP
- 120V and 240V (H) versions available
- 3400R is this product page
8400R — 2HP, 240V
- Fits all Kasco 8400 series units
- 3-year warranty
Key Features
Genuine Kasco OEM
- Factory replacement motor — not an aftermarket copy
- Restores original performance and efficiency
- Half the cost of replacing the whole unit
Built to Last
- Oil-cooled, continuous-duty design
- Sacrificial zinc anode on the motor shaft
- Safe for saltwater and harsh environments
120V & 240V Versions
- 3400R (120V) and 3400HR (240V) configurations
- Stub cord or full-length 25–100 ft cords
- One motor fits fountains, aerators, circulators & de-icers
